Details
Made to help young riders have fun and show off their skills, this mini dirt shredder features a purpose-built aluminum frame and 100mm suspension fork with 24-inch wheels. Trail-worthy MTB components including hydraulic brakes and a dropper seatpost add to its capabilities, giving kids what they need to follow their dirt dreams.
BUILT TO LAST
The ALUXX-grade aluminum frame and Crest TR Comp Lite 100 mm suspension fork are engineered to handle rough rides while keeping things smooth and controlled. The 24-inch TRA 2 WheelSystem with Wide Guard rim technology lets riders run lower tire pressures for added traction without sacrificing rim durability.
YOUTH-TUNED CONTROL
Designed for riders 125–145 cm tall, the STP 24 features youth-specific components that ensure proper fit and control. The narrower handlebars, Liv Grit Core Lite saddle, and Contact Switch AT Lite dropper seatpost provide a comfortable, secure riding position, while youth-tuned hydraulic disc brakes offer smooth, reliable stopping power across all terrain.
TRICK-READY HANDLING
With 24-inch wheels, front and rear thru-axles, and a short rear center, the STP 24 feels agile yet stable. Its low center of gravity makes it easier to lift the front wheel, pump through rollers, and carve corners with confidence and control.
| Frame Size | One Size |
|---|---|
| Seat Tube Length (mm) | 300 |
| Seat Post Insertion Depth (mm) | 250 |
| Seat Tube Angle | 73.0° |
| Top Tube Length (mm) | 523 |
| Head Tube Length (mm) | 90 |
| Head Tube Angle | 67.0° |
| Fork Rake (mm) | 30 |
| Trail (mm) | 104 |
| Wheelbase (mm) | 975 |
| Chain Stay Length (mm) | 375 |
| Bottom Bracket Drop (mm) | 40 |
| Stack (mm) | 534 |
| Reach (mm) | 360 |
| Stand Over Height (mm) | 629 |
| Handlebar Width (mm) | 640 |
| Stem Length (mm) | 40 |
| Crank Length (mm) | 140 |
Specs
| Frame | ALUXX-grade aluminum, 12x142mm thru-axle |
|---|---|
| Fork | Giant Crest TR Comp Lite, 34 mm stanchions, 15x110 mm thru-axle, 100 mm travel, youth tuned |
| Rims | Giant TRA 2, 24", alloy |
| Hubs |
Front: Giant Tracker, thru-axle, 6-bolt Rear: Giant Tracker thru-axle, 6-bolt, HG driver body |
| Spokes | Stainless, 14g |
| Tires | Kenda Amrak, 24x2.2" |
| Bottom Bracket | Threaded cartridge |
| Crankset | Alloy forged, 30t, 140mm |
| Shifters | MicroSHIFT Advent, 1x9, quick trigger shifter with small hand ergonomics and indicator with index thumb operation |
| Rear Derailleur | MicroSHIFT Advent, super short cage for increased ground clearance with clutch |
| Cassette/Freewheel | Shimano CS-H093, 11x38 |
| Chain | KMC X9 |
| Brakes | Tektro HD-J2820 hydraulic [F]180mm, [R]160mm rotors |
| Brake Levers | Tektro HD-J2820 |
| Handlebars | Giant Sport, alloy, 31.8 mm, 640 mm |
| Tape/Grips | Giant Junior |
| Stem | forged alloy, 0-degree |
| Seatpost | Giant Contact Switch AT Lite, remote, 70-100 mm travel, 30.9 mm x 315 mm |
| Saddle | Liv Grit Core Lite |
| Pedals | Platform |
* Subject to change without notice.
Part Numbers
| Option | UPC | MPN |
|---|---|---|
| Alpine Green / One Size | 04711291217447 | 1090036190 |
