Details
- Disc-specific, tubeless-ready clincher rim with Vibrocore, optimized for Gravel, Adventure, and MTB Cross Country use
- Vibrocore inner well reduces the transmission of harmful vibration frequencies, improving rider comfort and increasing the fatigue life of the rim
- Low-profile 16.5mm depth and wide 27.5mm outer width enhance radial compliance, improving traction while reducing negative feedback to the rider
- Asymmetric, 24mm inner width profile improves spoke tension balance between the drive-side and non-drive-side spokes and optimizes gravel/XC tire spread
- Bead Nip tubeless bead seats provide reliable tubeless performance, even at low pressures
Specs
Rim | Flare 24 Asymmetric aluminum |
---|---|
Brake Compatibility | 6-bolt disc |
Axle | 142 x 12mm |
Hub | SPANK HEX Gravel J-Type |
Spokes | J-hook triple butted 2.2/1.8/2 |
Spoke Count | 28 |
Nipples | Alloy external |
Lacing | 3-cross |
Inner Rim Width | 24mm |
Outer Rim Width | 28mm |
Rim Depth | 16.5mm |
Valve Type | Presta |
Extras | Tubeless taped & valved |
* Subject to change without notice.
Part Numbers
Option | UPC | MPN |
---|---|---|
142 x 12mm / SRAM XDR / Black / 700c | 4710155966484 | C090531RD2J320A |
